GSW-3100C

CTC Union Technologies unveils the brand new 10G CPE switch, GSW-3100C, which supports multigigabit technology for active Ethernet based FTTH application. This new 10G CPE switch is designed with 4 ports 10M/100M/1G/2.5Gbps and 1 port 10M/100M/1G/2.5G/5G/10Gbps RJ45 as well as 1 port 1G/10Gbps SFP+ based fiber optics. As usual, the GSW-3100C adopts the evolutionary cable tray structural design to help the installer more easily and protectively manage the excess fiber within the unit.

he GSW-3100C leverages the technology strength of chipset provider to enable the multigigabit speed feature. The enterprise and residential users will be able to experience the reliable and secure Ethernet based high speed network access and also connect the existing Cat5e/Cat6 cabling infrastructure with popular WiFi 6E/7 device, NAS access as well as small cell or powerful workstations to break through the limitation of 1Gbps data rate for content richer applications such as Cloud storage, 4K streaming video/game services or HD/UHD teleconferencing.

CTC Union Technologies adopts the new generation SoC single chip insides the GSW-3100C. It is developed through highly circuit integration and manufactured by the advance wafer process. Therefore, GSW-3100C can benefit a low power consumption and cost-effective targets from this SoC solution compared with the previous generation product which was the combination of multiple chips. However, The GSW-3100C remains supporting most of popular Layer 2 feature sets with network management interfaces such as Web GUI, SNMP. The GSW-3100C also supports ZTP (Zero Touch Provisioning) function which is suitable for the very largescale deployment from operator or service provider. These device management features can avoid truck rolls and save OPEX for FTTH service providers.
