Features and benefits
Easily connect and manage Ethernet-enabled devices
Store-and-forward technology and superior switch performance in industrial applications where ruggedness is required.
Designed for rugged environments
Hardened metal DIN-rail enclosure delivers top performance in demanding environments. High shock and vibration ratings. Case dimensions: 2.3” X 8.3” X 4.8”.
Flexibility with copper ports
Sixteen 10/100BaseTX RJ-45 ports.
Easy to use and flexible 10/100BaseTX ports
Auto-sensing for duplex and MDIX. Auto-configurable for maximum speed by default. Can also be hard coded. Wire speed capability on all 10/100BaseTX ports.
Easy to configure management functionality
Fully managed features are easily configurable from a web browser. Set up SNMP, VLAN, Quality of Service (QoS), port trunking, port mirroring, IGMP, SNMP and RSTP to your specifications.
DHCP Server for Automatic IP address assignment
DHCP Server assigns IP addresses automatically. Includes DHCP Option 82 relay, Option 61 and IP fallback.
Switch status monitoring and LED indicators
LED indicators are configurable to indicate power failure and N-Ring status.
Leading certifications for industrial environments
IEEE 1613 compliance. Suitable for hazardous environments with UL Class I, Division 2 listing and CE certifications. Over 2 million hours MTBF and operating temperature of -40 °C to 70 °C.
Real-time remote monitoring
N-View™ Windows-based software provides remote monitoring.
N -Ring™ technology with ~30ms healing time
N-Ring™ technology offers expanded ring size capacity to support up to 250 N-Tron managed switches. The ring manager provides complete fault diagnostics and ring health status via browser.
Enhanced Port Security
Port-based MAC address filtering delivers a high level of security to your network connections. Supports up to 8,000 MAC addresses.
Redundant power inputs and surge protection
Redundant power input (40-160 VDC). ESD and surge protection diodes on all ports.
