| OUTPUT |
| DC VOLTAGE |
24V |
36V |
48V |
| RATED CURRENT |
40A |
26.6A |
20A |
| CURRENT RANGE |
0 ~ 40A |
0 ~ 26.6A |
0 ~ 20A |
| RATED POWER |
960W |
957.6W |
960W |
| RIPPLE & NOISE (max.) Note.2 |
120mVp-p |
150mVp-p |
150mVp-p |
| VOLTAGE ADJ. RANGE |
24 ~ 29V |
36 ~ 42V |
48 ~ 55V |
| VOLTAGE TOLERANCE Note.3 |
±1.0% |
±1.0% |
±1.0% |
| LINE REGULATION |
±0.5% |
±0.5% |
±0.5% |
| LOAD REGULATION |
±1.0% |
±1.0% |
±1.0% |
| SETUP, RISE TIME |
500ms, 50ms/230Vac at full load |
| HOLD UP TIME (Typ.) |
15ms/230Vac at full load |
| INPUT |
| AC VOLTAGE RANGE |
180 ~ 264Vac |
| DC VOLTAGE RANGE |
254.5 ~ 370Vdc |
| NO LOAD POWER CONSUMPTION (Typ.) |
3.9W @ 230Vac |
| FREQUENCY RANGE |
47 ~ 63Hz |
| POWDR FACTOR (Typ.) |
PF>0.95/230Vac at full load |
| EFFICIENCY (Typ.) |
94.5% |
95% |
95.5% |
| AC CURRENT (Typ.) |
5A/230Vac |
| INRUSH CURRENT (Typ.) |
COLD START 30A/230Vac |
| LEAKAGE CURRENT |
<3.5mA / 240Vac |
| PROTECTION |
| OVERLOAD |
105~130% rated output power |
| Hiccup mode when output voltage <30%, recovers automatically after fault condition is removed |
| Constant current limiting without shutdown within 30%~100% rated output voltage, recovers automatically after fault condition is removed |
| OVER VOLTAGE |
30 ~ 34V |
43 ~ 50V |
56 ~ 65V |
|
Protection type : Shut down o/p voltage, re-power on to recover |
| OVER TEMPERATURE |
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down |
| FUNCTION |
| PARALLEL(Droop Mode) |
Up to 3840W or (3+1) units; Please refer to Function Manual for more details |
| DC OK RELAY CONTACT |
Relay Contact Ratings (max.): 30Vdc/1A, 30Vac/0.5A resistive load |
