XTR-960

$0.00

240W AC/DC 3 Input Ultra Slim Industrial DIN Rail Power

XTR-960 seri es:

XTR-960-24,

XTR-960-36,

XTR-960-48

Model:

XTR-960-24

XTR-960-36

XTR-960-48

240W AC/DC 3 Input Ultra Slim Industrial DIN Rail Power

XTR-960 seri es:

XTR-960-24,

XTR-960-36,

XTR-960-48

Wattage : 240W~960W

Features:

Three-phase 320 ~ 600Vac wide input range, support dual-phase operation
Ultra-low inrush current <10A
Global certificates in multi-fields:
CB / TUV / UL / RCM / BSMI / CCC / BIS / EAC / CE / UKCA (62368-1 + 61010-1 + 61558-1), and HazLoc C1D2 / marine DNV / SEMI 47
Ultra slim design: 48~96mm (by model)
High efficiency up to 96% and no-load power dissipation <2.5W~3.1W (by model)
150~200% peak power capability
Current sharing up to 3840W for parallel use (XTR-240 by request)
Over voltage category III (OVC III)
-40~+85℃ wide range operation temperature (>+60℃ derating)
Various terminal blocks: screw-type, push-in, lever-type
Internal PCB conformal coating protection
Can be installed on DIN Rail TS-35/7.5 or 15
5 years warranty

Specification Table Slider - XTR-960 Series

                    Specification
                    XTR-960-24☐◯☐=Blank, LA, PI    ◯=Blank, GL
                    XTR-960-36☐◯
                    XTR-960-48☐◯

                    OUTPUT

                    DC VOLTAGE
                    24V
                    36V
                    48V

                    RATED CURRENT
                    40A
                    26.66A
                    20A

                    CURRENT RANGE
                    0 ~ 40A
                    0 ~ 26.66A
                    0 ~ 20A

                    RATED POWER
                    960W
                    959.76W
                    960W

                    PEAK
                    80A
                    53.3A
                    40A

                    1920W
                    1918.8W
                    1920W

                    RIPPLE & NOISE (max.) Note.2
                    120mVp-p
                    150mVp-p
                    150mVp-p

                    VOLTAGE ADJ. RANGE
                    24 ~ 29V
                    36 ~ 42V
                    48 ~ 55V

                    VOLTAGE TOLERANCE Note.3
                    ±1.0%
                    ±1.0%
                    ±1.0%

                    LINE REGULATION
                    ±0.5%
                    ±0.5%
                    ±0.5%

                    LOAD REGULATION
                    ±1.0%
                    ±1.0%
                    ±1.0%

                    SETUP, RISE TIME
                    800ms, 60ms/400Vac      600ms, 60ms/500Vac at full load

                    HOLD UP TIME (Typ.)
                    20ms / 400Vac      20ms / 500Vac at full load

                    INPUT

                    VOLTAGE RANGE Note.4
                    Three-Phase 320 ~ 600Vac (Dual phase operation possible)    450 ~ 800Vdc

                    NO LOAD POWER CONSUMPTION (Typ.)
                    3.1W/400Vac
                    3.1W/400Vac
                    3.1W/400Vac

                    6.5W/400Vac
                    6.5W/400Vac
                    6.5W/400Vac

                    FREQUENCY RANGE
                    47 ~ 63Hz

                    POWER FACTOR (Typ.)
                    PF≥0.92/400Vac      PF≥0.9/500Vac at full load

                    EFFICIENCY (Typ.)
                    95%
                    95.5%
                    96%

                    AC CURRENT (Typ.)
                    2A/400Vac      1.4A/500Vac

                    INRUSH CURRENT (Typ.)
                    COLD START      10A/500Vac

                    LEAKAGE CURRENT
                    <3.5mA / 530Vac

                    PROTECTION

                    OVERLOAD
                    105%~200% rated output power for more than 5 sec then constant current limiting without shutdown at rate current when Vo=30%~100%

                    Hiccup mode when Vo<30% rated voltage

                    OVER VOLTAGE
                    30 ~ 35V
                    43 ~ 50V
                    56 ~ 65V

                    Protection type : Shut down o/p voltage, re-power on to recover

                    OVER TEMPERATURE
                    Shut down o/p voltage, recovers automatically after temperature goes down

                    FUNCTION

                    PARALLEL
                    Up to 3840W (3+1), please refer to Function Manual for more details

                    DC OK RELAY CONTACT
                    Relay Contact Ratings (max.):30Vdc/1A, 30Vac/0.5A resistive load

                    REMOTE CONTROL
                    Power ON : RC + ~ RC- open or keep 2~5Vdc

                    Power OFF: RC + ~ RC- short or keep<0.5Vdc
